Venture Machine & Tool, inc. can produce small, simple parts to large complex 3D parts, we engineer and build all of our stamping tools through production phase. Where we will ship the tooling to our customer for them to run or we will run there tooling in house.
Features and Benefits
- In-house design engineers work in conjunction with Venture’s tool and die builders to ensure quality and accuracy
- Equipment is inspected and maintained as per our internal audit system which is driven by ISO 9001
- Experienced journeymen tool and die builders
Value Added Operations
- In-house tool design
- In-house engineering
- Prototype development
- In-house tool repair
Types of Tooling Produced
- Progressive Complete Dies
- Prototype
- Draw Dies up to 8″ (progressive)
- Secondary Hand Transfer Dies
- Servo Transfer Press Tooling
- Blanking (Progressive and Compound)
- Decorative Aluminum over Plastic Wrap Tooling
- Self-Contained Die Transfer Systems
- Progressive Mandrel (Horn) Dies
- Cam Tooling (Trim, Pierce, Form, Thread)
Tooling Equipment
| Machine Centers | Travel Envelope | Spindle | Equipped for |
|---|---|---|---|
| 1 – OKK Horizontal | x60″ y60″ z24″ with 30 HP | 50 taper | |
| 1 – Dahlih Vertical | x84″ y34″ z27″ with 30 HP | 4500 chilled | Equipped for DNC |
| 3 – Dahlih Vertical | x54″ y26″ z27″ with 20 HP | 50 taper spindle | Equipped for 3-D DNC |
| 1 – HaasVertical | x40″ y20″ z27″ with 15 HP | 40 taper, 10,000 RPM | Equipped for 3-D DNC |
| 1 – Devlieg Horizontal | x72″ y60″ z24″ with 30 HP | 50 taper | |
| 1 – VF4000 | x165″ y90″ z36″ with 60 HP | thru spindle coolant | Renishaw Probe |
| 1 – Makino A71 Horizontal | x29″ y29″ z31″ | 50 Taper | Renishaw Probe |
| Milling Machines | Table | HP | |
|---|---|---|---|
| Ten (10) Bridgeport Vertical Conventionals | 4′ (12″ x 48″) | Digital Readouts | |
| Brown and Sharpe Horizontal | 52″ | ||
| Kearney and Trecker S-15 315 | Horizontal | 16″ x 72″ | |
| Devlieg Horizontal Mill | x72″ y60″ z24″ | 30 | |
| Cincinnati Vertical Mill | x18″ y70″ z24″ | 50 taper | 15 |
| Cincinnati Vertical Mill | x20″ y84″ z36″ | 50 taper | 15 |
| Grinders | ||
|---|---|---|
| Two (2) Harig | 6″ x 12″ Chuck Z-9″ | Duo form dressing |
| Harig | 6″ x 18″ Chuck Z-9″ | Duo form dressing |
| Brown and Sharpe | 8″ x 18″ Chuck Z-9″ | Hydraulic Downfeed |
| Abrasive | 10″ x 16″ Chuck Z-12″ | Duo form dressing |
| Okomoto | 28″ x 48″ Chuck Z-24″ | Automatic dresser, Hydraulic Downfeed |
| Kent | 14″ x 44″ Chuck Z-24″ | Hydraulic with incremental down |
| Thompson | 20″ x 70″ Chuck Z-48″ | Hydraulic with incremental down |
| Okomoto | 12″ x 24″ Chuck Z-12″ | Automatic dresser, Hydraulic Downfeed |
| Saws | ||
| Grob 4-V-36 | 18″ throat air feed saw | Table Top |
| Kalamazoo | 24″ wide Cutoff saw | |
| Doall | 48″ throat air feed saw | Table Top |
| Kalamazoo | 24″ wide Cutoff saw | |
| Drill Presses | ||
| Cincinnati | 5′ radial arm | |
| Cincinnati | 4′ sensitive radial arm | |
| Carlton | 4′ radial arm | |
| American | 4′ sensitive arm | |
| Four (4) Avey | 36″ table type |
| Jig Mills | Table | Travel Envelope | |
|---|---|---|---|
| CNC Devleig 4K-72 | 40″ x 70″ CNC Rotary Table | 72″ x 60″ x 24″ | 8300 Allen Bradley 4 axis simultaneous control 3-D DNC |
| Devleig 3B48 | 36″ x 48″ | 50″ x 36″ x 16″ | .0001 resolution digital readout |
| Plunge EDM’s | Work Tank | Power Supply | |
| Elox 8-20-13 | 20″ x 36″ | Astra 200-D | |
| Elox HRP – 89 Plunge | 20″ x 36″ | Astra 200-D | |
| Makino Orbital | 36′ x 60″ | ||
| 3D Laser Machines | |||
| Mazak 6 Axis Laser | Super Turbo 3D 6 Axis Laser 2,000 watt | Bed 80″ x 120″ Z CAD programmable | |
| Mitsubishi | 3,000 watt | Bed 86″ x 122″ Z CAD programmable | |
| Heat Treat Furnaces | |||
| Mifco | Atmospherically controlled | 12″ x 12″ x 24″ | |
| Electra | Atmospherically controlled | 15″ x 20″ x 36″ | |
| Tempering Ovens | |||
| Wire EDM’s | Travel Envelope | ||
|---|---|---|---|
| Elox Model Q4 | 4 axis wire cut | Color graphics | 20″ x 14″ x 8″ |
| Fanuc Model W | 2 axis wire cut | Color graphics | 20″ x 14″ x 8″ |
| Fanuc Robocut Alpha 1A | 4 axis wire machine with auto wire feed | 17″ x 13″ x 12″ | |
| Fanuc Robocut Alpha 1C | 4 axis wire machine with auto wire feed | 17″ x 14″ x 12″ | |
| Fanuc Robocut Alpha iC | 4 axis wire machine with auto wire feed | 17″ x 14″ x 12″ |
| Lathes | Swing on Face Plate | |
|---|---|---|
| South Bend | Toolmaker’s Lathe 5″ diameter | |
| Three (3) Webb lathes | 40″ gap bed | 23″ diameter |
| Martin lathe | 60″ gap bed | 40″ with mimic tracer |
| Inspection | ||
| Six (6) Granite Inspection Surface Plates | Various Sizes | |
| Cadillac Gauges | Up to 48″ | |
| Mitutoyo Bright Apex 916 Coordinate Measuring Machine | x36 y63 z24 | |
| Design/Engineering/Programming/Networking/Email/Software | ||
| Eight (8) Design/Engineering | Solidworks 2008/Autocad 2000 | |
| Laser Programming | Surfcam | |
| Three (3) Machine Center | Surfcam/Powermill | |
| Wire EDM | Surfcam | |
